- Código RS:
- 186-9719
- Referência do fabricante:
- MC14014BDG
- Fabricante:
- onsemi
Temporariamente fora de stock. Disponível a 10/06/2024, com entrega em 4 dia(s) útil(eis).
Adicionado
Preço unitário (Fornecido em múltiplos de 25)
0,601 €
Unidades | Por unidade | Por Pack* |
25 - 75 | 0,601 € | 15,025 € |
100 - 475 | 0,48 € | 12,00 € |
500 - 975 | 0,378 € | 9,45 € |
1000 - 2475 | 0,297 € | 7,425 € |
2500 + | 0,29 € | 7,25 € |
*preço indicativo |
- Código RS:
- 186-9719
- Referência do fabricante:
- MC14014BDG
- Fabricante:
- onsemi
Documentação Técnica
Legislação e Conformidade
Detalhes do produto
Registradores de desplazamiento y contadores serie 4000, ON Semiconductor
The MC14014B and MC14021B 8-bit static shift registers are constructed with MOS P-channel and N-channel enhancement mode devices in a single monolithic structure. These shift registers find primary use in parallel-to-serial data conversion, synchronous and asynchronous parallel input, serial output data queueing, and other general purpose register applications requiring low power and/or high noise immunity.
Synchronous Parallel Input/Serial Output (MC14014B)
Asynchronous Parallel Input/Serial Output (MC14021B)
Synchronous Serial Input/Serial Output
Full Static Operation
"Q" Outputs from Sixth, Seventh, and Eighth Stages
Double Diode Input Protection
Supply Voltage Range = 3.0 Vdc to 18 Vdc
Capable of Driving Two Low-power TTL Loads or One Low-power Schottky TTL Load Over the Rated Temperature Range
MC14014B Pin-for-Pin Replacement for CD4014B
MC14021B Pin-for-Pin Replacement for CD4021B
Asynchronous Parallel Input/Serial Output (MC14021B)
Synchronous Serial Input/Serial Output
Full Static Operation
"Q" Outputs from Sixth, Seventh, and Eighth Stages
Double Diode Input Protection
Supply Voltage Range = 3.0 Vdc to 18 Vdc
Capable of Driving Two Low-power TTL Loads or One Low-power Schottky TTL Load Over the Rated Temperature Range
MC14014B Pin-for-Pin Replacement for CD4014B
MC14021B Pin-for-Pin Replacement for CD4021B
Familia lógica 4000 CMOS, ON Semiconductor
Dispositivos de la familia CMOS
Amplia gama de tensión de funcionamiento: 3 a 18 V
Amplia gama de tensión de funcionamiento: 3 a 18 V
Especificações
Atributo | Valor |
---|---|
Tipo de Encapsulado | SOIC |
Función Lógica | Registro de desplazamiento |
Número de Fases | 8 |
Tipo de Montaje | Montaje superficial |
Modo de Funcionamiento | De paralelo a serie |
Conteo de Pines | 16 |
Tensión de Alimentación de Funcionamiento Mínima | 3 V |
Tensión de Alimentación Máxima de Funcionamiento | 18 V |
Dimensiones | 10 x 4 x 1.5mm |
Estándar de automoción | AEC-Q100 |
Temperatura de Funcionamiento Mínima | -55 °C |
Temperatura Máxima de Funcionamiento | 125 °C |
